South Creative LED Displays Power Supply 200W NDG200HS5
South Creative LED Displays Power Supply 200W NDG200HS5
Couldn't load pickup availability
South Creative LED Displays Power Supply 200W NDG200HS5 series Features:
South Creative NDG200HS5 LED Screen Power Supply has the characteristics of small size, high efficiency, stable operation, high reliability, high efficiency and energy saving. The power supply has input over-voltage, output over-current and output short-circuit protection; the power supply adopts high-efficiency synchronous rectification circuit to greatly improve the efficiency of the power supply, and the efficiency is as high as 87%, which greatly saves energy.
| Model Name | NDG200HS5 |
| Input Voltage Range | 190-264 Vac |
| Input Frequency Range | 47-63 Hz (Typ 50/60) |
| Output DC Voltage Range | 4.9-5.1 Vdc(Typ 5) |
| Output Rated Current | 40 A |
| Max Power | 200 W |
| Efficiency | ≥87%(220Vac full load) |
| Dimension (L*W*H) | 142*59*30mm |
View More
South Creative NDG200HS5 LED Screen Power Supply Specification
