Rong-Electric MDH200H5 LED Displays Power Supply For Transparent LED Video Wall
Rong-Electric MDH200H5 LED Displays Power Supply For Transparent LED Video Wall
Couldn't load pickup availability
Rong-Electric MDH200H5 LED Displays Power Supply Features:
2.43 MDH200H Series
Input Voltage:186-264Vac, 47-63Hz
Output Power:200W Max
Insulation:I/P-O/P:3.0KVac;I/P-FG:1.5KVac;O/P-FG:0.5KVac
Leakage Current:0.30mA@230Vac
Protection Function:Input Undervoltage,Over Load,Short,etc.
Operating Temperature:-30~+60℃
Storage Temperature:-40~+100℃
Safety Standards:GB4943,EN60950
Cooling Mode:Self-cooling
dimension:142*58*30mm
Rong-Electric MDH200H5 5V60A 300W LED Display Power Supply Parameters:
Model:MDH200H
Category:constant voltage
Output voltage:5V
Output current:40A
Ripple and noise:<150mV
Efficiency:89%
Watts:200W
Output:Single
Size:142X58X30
