Rong-Electric LED Displays Power Supply MD200PC5 5V40A 200W LED Display Power Supply

Rong-Electric LED Displays Power Supply MD200PC5 5V40A 200W LED Display Power Supply

Regular price $36.00 USD
Regular price $55.00 USD Sale price $36.00 USD
Sale Sold out
Shipping calculated at checkout.
Model Number

Rong-Electric MD200PC5 LED Displays Power Supply Features:

Input Voltage:100-240Vac 200-240Vac, 47-63Hz
Power Factor:0.50@230Vac
Leakage Current:0.30mA@230Vac
Protection Function:Input Undervoltage,Over Current,Short
Operating Temperture:-30~+60℃
Cooling Mode:Self-cooling
Insulation:I/P-O/P:3.0KVac;I/P-FG:1.5KVac;O/P-FG:0.5KVac

Rong-Electric MD200PC5 5V40A 200W LED Display Power Supply Parameters:
Input Voltage:90-264Vac, 47-63Hz
Output Power:200W Max
Power Factor:0.98@230Vac
Insulation:I/P-O/P:3.0KVac;I/P-FG:1.5KVac;O/P-FG:0.5KVac
Leakage Current:0.30mA@230Vac
Protection Function:Input Overvoltage,Over Temperature,Over Load,Short,etc.
Operating Temperature:-30~+60℃
Storage Temperature:-40~+100℃
Safety Standards:GB4943,EN60950
EMC Standards:GB9254,EN55022A
Certification:CE,CCC,UL,CB
Cooling Mode:Self-cooling
Dimension:208*60*30mm

Type Number Type Output Voltage Output Current Ripple& Noise Effi. Remarks
MD200PC5 CV 5V 40A < 150mV 90.00%
MD200PC4.5 CV 4.5V 40A < 150mV 89.00%
MD200PC4.2 CV 4.2V 40A < 150mV 88.00%
MD200PC3.8 CV 3.8V 40A < 150mV 87.00%
MD200PC3.3 CV 3.3V 40A < 150mV 86.00%


Futher Information:
MD200PC5
Rong-Electric MD200PC5 High Efficiency LED Screen Power Supply Specification
