CZCL LED Displays Power Supply A-200AF-4.5 4.5V40A Low Profile LED Power Supply

CZCL A-200AF-4.5 4.5V40A 200W Low Profile LED Displays Power Supply Features:

A-200AF-4.5 is Led display power supply without fans. The input voltage rang is 180～264VAC and output voltages are 4.5V. It can be applied to Led display、LED indicator light and other Led display fileds. This series product is ultra-thin design, with a height of only 30mm, and can adapt to a variety of box size requirements. Super high efficiency, compact shell design and good heat dissipation ensure the long-term stable work of this series of products.

CZCL A-200AF-4.5 4.5V40A 200W Low Profile LED Displays Power Supply Parameters:

Input voltage:200-240Vac,47-63Hz
Protection:undervoltage,Overload,Short circuit
Output power:200W Max
Working temperature:-30~+60℃
Power factor:0.50@230Vac
Storage temperature:-40℃~+100℃，20~95%RH
Insulation voltage:I/P-O/P:3.0KVac
Safety standards:GB4943，UL60950-1，EN60950-1
I/P-FG:1.5KVac;O/P-FG:0.5KVac,1min
Dissipate heat:cold
EMC Standards:: GB9254，EN55022
Protecting Time: 50ms, 20ms over load
Leakage current:0.30mA@230Vac
Size:190×82×30

View More
CZCL A-200AF-4.5 LED Displays Power Supply Specification
