CL LED Displays Power Supply A4-200-5P 5V40A Low Profile LED Power Supply

CL LED Displays Power Supply A4-200-5P 5V40A Low Profile LED Power Supply

Regular price $23.00 USD
Regular price Sale price $23.00 USD
Sale Sold out
Shipping calculated at checkout.

CL A4-200-5P 5V40A 200W Low Profile LED Displays Power Supply Features:

Input Parameter:

  • Input Voltage Range: 180~264Vac
  • Input Frequency Range:  50/60
  • AC Current: ≤1.8A(100Vac, full load)

Output Parameter:

  • Dc Voltage Range:5 V
  • Rated Current: 40A
  • Max power: 200W
  • Ripple & Noise: ≤120mVp-P
  • Efficiency (Typ):≥79% Vin=220Vac,
  • Voltage Tolerance:±2%
  • Power on delay time<2S

Protection:

  • OCP(65-75A)
  • SCP(Hiccup mode, auto recovery after fault condition is removed)

Safety&EMC:

  • EN60950-1,EN55022
  • Hi-pot: I/P-O/P: 3.0KVAC/ 10mA/ 60S,I/P-FG:1.5KVAC/ 10mA/ 60S ,O/P-F/G: 500Vdc/10mA/1min
  • Isolation Resistance: 100MΩ Max/ 500VDC/ 3S
  • Leakage current<0.75mA(AC240V)

Others:

  • Working Temperature:-10℃ ~ +50℃
  • Cooling: ventilate by air convection
  • Working Humidity:5%~90%RH
  • Storage temperature: -20℃~+85℃
  • Dimension (L*W*H):200×99×31mm
  • Carton Dimension: 46*34.5*23CM
  • Packing:32PCS/ 19.2KG/CTN/0.04CBM
  • MTBF:50K hours (MIL-HDBK-217F (25 )
